NSDRC RS100 High-Torque Micro Servo

NSDRC RS100 High-Torque Micro Servo

Between small-scale crawlers, two-speed transmissions, dig setups, and other auxiliary needs, you can never have enough micro servos. The folks at No Superior Designs RC has released its newest pint-sized servo in the form of the RS100 High Torque Micro Servo.

Wrapped in an aluminum case, the RS100 is water-resistant and features steel gears for ultimate durability.

NSDRC RS100 High-Torque Micro Servo Specs:

  • Torque/Speed Ratings
  • 105oz/ 7.5kg / 0.10 @ 5v
  • 120oz/ 8.6kg / 0.09 @ 6v
  • 143oz/ 10.3kg / 0.07 @ 7.4v
  • 165oz/ 11.9kg / 0.06 @ 8.4v
  • Operating Voltage: 5v – 8.4v
  • Hardened Steel Gears
  • Spline: 25T 4.9mm Micro
  • Voltage: 5v-8.4v
  • Bearing: 2BB
  • Wire Length: 185mm
  • Weight: .70 oz / 20 Grams
  • Dimensions: 23 x 12 x 26mm
  • Water Resistant with 7 point O-ring seal (Not Submarine proof, do not submerge)

Priced at $54.99, the RS100 High-Torque Micro Servo can be purchased online at
